ADPC-48-450-U – Adaptive Power Cyclo – PID PWM Temperature Controller

USB Programming Interface: Allows for easy connection to a PC for programming and evaluation.
NTC Sensor Input: Default setting at 10k Ohm for accurate temperature sensing.
Operating Mode Feedback LEDs: Provides visual status for operating modes and fault conditions.
Manual Set Temperature Control: Enables manual adjustment of the desired temperature.
Dual Fan Driver Outputs: Supports two fans, improving heat dissipation and system efficiency.
Thermoelectric Driver Output: Low loss PWM power stage output for driving thermoelectric modules and assemblies.
Wide Input Voltage Range: Operates from 11 to 48V DC, accommodating various power sources.
Load: Supports loads up to 7A, suitable for most applications.
Broad Temperature Control Range: Control temperature from -5°C to +60°C with high accuracy using a proprietary auto adapt PID control loop.
Multiple Protection Mechanisms: Includes overcurrent, overvoltage, undervoltage lockout, and fuse protection for enhanced safety.
Expansion Port: Supports additional optically isolated modules for RS232, RS485, and 0-10V/4-20mA communication options.
Compact Design: Efficient use of space with a small footprint and clear connection layout.
Built in thermal management: Thermally optimised mounting frame as standard
